Views: 0 Author: Site Editor Publish Time: 2025-11-06 Origin: Site
Choosing the right Type 2 to Type 2 charging cable is essential to ensure efficient charging, safe use, and long-term durability. Here are the main factors you should consider before purchasing:
EVs have different on-board charger capacities. Even if the cable supports 22kW, your charging speed also depends on your vehicle’s limit.
| Vehicle Type | Typical AC Charging Power | Recommendation |
|---|---|---|
| Plug-in Hybrid (PHEV) | 3.3kW–7.4kW | 7kW cable is sufficient |
| Electric Vehicle (BEV) | 7.4kW–22kW | Choose an 11kW or 22kW cable |
| Commercial / Fleet Use | 22kW preferred | Always select 22kW for future flexibility |
Tip: If unsure, choose 22kW — it works on lower-power stations and future-proofs your setup.
Cable length affects convenience. Too short = hard to connect. Too long = messy and heavy.
| Parking Condition | Suggested Length |
|---|---|
| Home charging with fixed parking spot | 3m – 5m |
| Public parking with variable distance | 5m – 7m |
| Large vehicles / fleet yards | 7m – 10m |
The outer jacket material determines flexibility and lifespan.
| Material | Characteristics | Recommendation |
|---|---|---|
| PVC | Stiff, easy to crack in cold weather | Not recommended for outdoor daily use |
| TPU (best) | Flexible, wear-resistant, high temperature & cold tolerance | Recommended for long-term outdoor use |
If you frequently charge outdoors or live in a region with weather extremes, choose TPU.
Look for cables that meet international testing standards.
CE / TUV / UKCA / UL certification
IP55 or higher waterproof rating
Flame-retardant and impact-resistant housing
Silver-plated terminals for stable current transmission
The higher the certification level, the safer the charging performance.
A reliable manufacturer should offer:
Clear warranty coverage (usually 1–3 years)
Replacement support for quality issues
Technical assistance for commercial projects
Good after-sales service is especially important for charging station installers, retailers, and fleet operators.
Does my car use a Type 2 port?
Do I mainly charge at home or public stations?
What’s my vehicle’s AC charging limit?
Do I want future-proofing? (→ Choose 22kW)
Do I need flexible length based on parking conditions?
